Product Details
| PCB-1012–E5G5R
(Europe) 5G |
PCB-1012–E5G5G GPS
(Europe) 5G |
PCB-1012–A5G5R
(America) 5G + 5GHz |
PCB-1012–A5G5G GPS
(America) 5G + 5GHz |
| 738-830MHz: 1.0W
5G, 4G LTE Low |
738-830MHz: 1.0W
5G, 4G LTE Low |
850-895MHz: 1.0W
CDMA 850 |
850-895MHz: 1.0W
CDMA 850 |
| 920-965MHz: 1.0W
GSM900 |
920-965MHz: 1.0W
GSM900 |
1800-2000MHz: 1.0W
DCS, PCS |
1800-2000MHz: 1.0W
DCS, PCS |
| 1800-1920MHz: 1.0W
DCS |
1800-1920MHz: 1.0W
DCS |
2100-2170MHz: 1.0W
3G, UMTS |
2100-2170MHz: 1.0W
3G, UMTS |
| 2100-2170MHz: 1.0W
3G, UMTS |
2100-2170MHz: 1.0W
3G, UMTS |
2300-2500MHz: 1.0W
4G LTE + WiFi 11.b & g |
2300-2500MHz: 1.0W
4G LTE + WiFi 11.b & g |
| 2300-2500MHz: 1.0W
WiFi 11.b & g |
2300-2500MHz: 1.0W
WiFi 11.b & g |
2500-2700MHz:1.0W
4G WiMAX Sprint |
2500-2700MHz:1.0W
4G WiMAX Sprint |
| 2570-2690MHz:1.0W
4G LTE High |
2570-2690MHz:1.0W
4G LTE High |
700-805MHz: 1.0W
4G LTE USA iPhone (AT&T & Verizon) |
700-805MHz: 1.0W
4G LTE USA iPhone (AT&T & Verizon) |
| 1420-1620MHz 1.0W
5G+ GPS L1 +Glonass L1 |
1420-1620MHz 1.0W
5G+ GPS L1 +Glonass L1 |
1570-1620 MHz: 1.0W
GPS L1 + Glonass L1 |
1570-1620 MHz: 1.0W
GPS L1 + Glonass L1 |
| 5G 3400-3800MHz 1.0W
5G |
5G 3400-3800MHz 1.0W
5G |
5G 617-652MHz 1.0W
5G |
5G 617-652MHz 1.0W
5G |
| 433MHz :1.0W
Remote Control |
1370-1390MHz: 1.0W
GPS L1 3+ L4 |
173MHz 1.0W (or GPS LoJack 173 | 173MHz 1.0W (or GPS LoJack 173 |
| 164-173MHz :1.0W
Lojack 164MHz |
164-173MHz :1.0W
Lojack 164MHz |
433MHz :1.0W
Remote Control |
1170-1280MHz: 1.0W
GPS L2 + L5+ Glonass L2 |
| 868MHz: 1.0W
Remote Control |
1170-1280MHz: 1.0W
GPS L2 + L5+ Glonass L2 |
5G 3400-3800MHz 1.0W
5G |
5G 3400-3800MHz 1.0W
5G |
| 5.1-.5.8GHz :1.0W
WiFi 11.a |
5.1-.5.9GHz :1.0W
WiFi 11.a |
5.1-.5.9GHz :1.0W
WiFi 11.a |
5.1-.5.9GHz :1.0W
WiFi 11.a |
| Total: 12.0 W | Total: 12.0 W | Total: 12.0 W | Total: 12.0 W |
| Power supply: | AC100-240V or 12V Car Charger | ||
| Jamming Range | Radius 10–30 meters (-75dBm@Omnidirectional antennas) | ||
| Working time: | 4.0 Hours, Battery：Ni-Mh battery 12000mAH
Can Turn on and Charging at the same time, Each Band can Turn ON/OFF, |
||
| Weight | 1.5 Kg | ||
| Dimension: | 160 x 105 x 50mm (Main Unit only, do not include Antennas) | ||
| Warranty: | 1 year | ||
| Europe Type: 12 Bands
1: 164-173MHz Lojack 2: 1800-1920MHz: DCS, GSM1800, PHS, PCS, CDMA1900 3: 2100-2170MHz: UMTS, 3G, WCDMA, TD-SCDMA, CDMA2000 4: 2570-2690MHz: 4G High WiMax2, 4G LTE 5: 1570-1620MHz GPS L1 + Glonass L1 6: 920-965MHz: GSM900 7: 2400-2500MHz: WiFi/Bluetooth 11.b. g. 8:758-830MH: 5G, 4G Low LTE , 4G WiMax 9: 3400-3800MHz 5G LTE 10: 1450-1500MHz: 5G LTE 11:868MHz: Car Remote or GPS L2+L5 12: 5.1-5.9GHz: WiFi 5GHz 11.a |
America Type:12 Bands
1: 173MHz Lojack 2: 1800-1990MHz: GSM, GSM1800, PHS, PCS, NEXTEL, CDMA1900, GSM1900 3: 2100-2170MHz: UMTS, 3G, WCDMA, TD-SCDMA, CDMA2000 4: 2500-2700MHz: 4G Wimax (Sprint), 4G High LTE 5: 1570-1620MHz GPS L1 + Glonass L1 6: 850-895MHz: CDMA 850 7: 2300-2500MHz: WiFi/Bluetooth 11.b. g.+ 4G LTE 8: 720-805MHz 4G LTE iPhone (AT&T & Verizon) 9: 617-652MHz 5G 10: 5.1-5.9GHz: WiFi 5GHz 11.a 11:868MHz: Car Remote or GPS L2 + L5 12: 433MHz: Car Remote or GPS L3 + L4 |
Techwise PCB-1012-5G5 New 12 Bands 12W Handheld 5G Mobile Phone WiF GPS Lojack Jammer
12 Bands 12.0W with Car Charger
Temperature Lower than 40℃
Work 4.0 Hours,12000mAH Battery
Can Turn on and Charging at same time
5G LTE + 5GHz
